TIDIGARE PROJEKT (ENGLISH)

RELAY HOST FOR PARTICLE

A board with power supply and relay outputs hosting a particle b-series mobile connectivity controller. Industrial quality with DIN enclosure.

TEXTILE INTRUSION ALARM

Prototype device to evaluate intrusion detection by sewn-in flexible threads in textile based enclosures.

SERVICE KIT CARRY CASE

Design and production of 10x carry cases for service technicians standard service kit.

RELAY BOARD REBUILD

A rebuild with retrofit replacement relays to keep costs down (original relays no longer produced and available only at an uncomfortable premium). Replacements with uncommon 2xNC + 2xNO and matched force-guided contacts for identical electrical safety behavior.

M-BUS/MODBUS CALCULATOR/CO-PROCESSOR

An industrial product that acts as a co-processor for automation systems. It is configured with data sources and mathematical formulas using a built-in webserver over Ethernet and collects data from external devices using Modbus over Serial and Ethernet. Calculations are performed with IEEE 754 double precision and delivered over an M-Bus link to the host automation system.

SPECIAL PURPOSE CAPACITOR BANK

A low-cost capacitor bank designed to replace organic aluminum polymer capacitors with ceramics for extremely high ripple current. The capacitor bank is 1000µF, 50V with an ESR of 5mOhm (tunable) with a peak current capability of over 2000A and a maximum production cost of €10. The circuit in which it is used intermittently charges and discharges the capacitor at approximately 50kHz, which no existing capacitor was able to withstand.

LORA-THE-EXPLORER

Product design for a long-range (up to 8km), long stand-by (up to 2 years) hand held/wall mounted LORA-radio system for use in remote read-out or control applications, such as gate openers, remote-area proximity detection and general use.

PORTABLE AUTOMATION SYSTEM

Design and assembly of a portable flight-case system and connectors panel to house the customers existing automation system, radio modem and support electrics, for demo and rapid response installations.

DUCTIG-ALPHA

Development and deployment of a duct crawling robot with HD video feedback and pressurized air tooling, primarily for use in cleaning and inspection of square or round ventilation ducts of 200mm or more.

SOUND EFFECTS BOX

Assembly of medium quantity Arduino-based (clients own design) MP3 sound effects boxes with external triggers, including the adaptation of enclosures by CNC-machining.

LABORATORY CONTROLLER

Schematic and board design for a touch-screen enabled measurement and control system for use by laboratories in inflammatory response research. The board controls up to 9 high current motors or other actuators and logs digital and analog signals from various sensors.

ELECTRICITY CONTROL AND METROLOGY

Six parallel electricity meters with relays, for remote metering and control via iPhone/Android app.

LED EYES FOR TUNGEVAAG & RAABAN

Construction of programmable LED inserts for 3D printed DJ-mask by Drafts & Design.

Flexible PCBs designed to conform to a curved 3D surface with 48 nano-sized, individually programmable RGB LEDs for each eye - all controlled by a NodeMCU for interfacing with a cell phone over WiFi.

SIGNAL GENERATOR

An analog differential signal generator ±10V, 2.5 ampere.

Designed for bench testing hydraulic valves.

MUSIC AND LIGHT SWINGS

A project by Utskottet Vision AB.

We developed the electronics and software for these interactive music- and light-swings, an installation at Metropolis by Light, Malmö 2018.

RE-FABRICATION OF CONTROLLER FOR HYDRAULIC LIFT

The electronics of this and many other old industrial machines like it are wearing out and starting to break down. To avoid breaking certifications we manufactured a series of identical boards, including the sourcing of original components that had been out of production since the '70s. The new boards now keep the system running without the need to install a modern PLC system which would have been been a very expensive solution requiring reverse-engineering, programming of replacement PLC logic and re-certification of the system.

SOUND EFFECTS BOX

DSp designed the electronics and software for this small, battery operated, sound effects generator. Focus was on high sound quality given its small size, as well as very low energy consumption, as the device is battery operated and spends most of its time "sleeping" between waking up at regular intervals to play sound effects from an SD card.

Watch the video of the early prototype

LABORATORY VALVE CONTROLLER

Our client had a significant number of four-port laboratory valves for fluid and gas transport. The valves were old but fully functional - but information on how to drive them, as well as the original electronics, had been lost. Replacing the valves themselves would be very expensive. We researched the valves and constructed a number of these boards to interface between existing RS-232 equipment and the valve motors and their feedback optics to accurately position the valves according to simple external commands.

RE-FABRICATION OF CONTROLLER FOR HYDRAULIC PRESS

The original electronics from an industrial hydraulic press had failed due to old age and previous repair attempts had only been able to prolong its life for short periods each time. DSp reverse-engineered (with permission) and re-engineered the control system to produce a drop-in replacement board with modernized and much more rugged components. The PCB was manufactured in house allowing us to get the machine back in service very quickly.

KIT BOARDS FOR KIDS

A series of boards designed for CoolMinds as part of their electronics education offer.

The boards were designed with focus on ease of assembly, having extra large pads and educational silkscreening.

Branding of the boards was done by converting the logo for tin plating + silkscreen as well as color matching of the solder mask.

INTERACTIVE AUDIOVISUAL SYSTEM

We developed the ZenScape system for interactive or passive installations.

Each lamp senses proximity, acceleration and rotation and provides light and sound output.

Highly configurable for a wide range of installations indoors or outdoors.

Watch the video demonstrating four channel distributed music and light effects

Watch the video [broken link] demonstrating various effects and interaction

POCKET DRIVE - MOTOR & MOTION CONTROL SYSTEM

This is our universal motor driver (DC, DC with encoder, stepper motor, three phase) for small motors.

Has exceptional interfacing capabilities (I2C, SPI, UART, Classic RC servo, Futaba RC servo, Analog, Digital) and a very fast, precise and fully capable (jog, relative, absolute, synchronized) trapezoidal motion planner.

Watch the video of the board running some very rapid stepper motor movements.

The clock is moving backwards - we actually had to slow down the movement to be able to catch it on camera.

"THE CUBE"

A project by Utskottet Vision AB.

We developed the electronics and software for this interactive sound- and lights-cube promoting love and closeness by requiring people to connect the internal metal spheres by holding hands to produce a variety of sound and lighting effects.

INTELLIGENT RS485/USB INTERFACE

Typical same-day-delivery project. This is a programmable interface between USB and RS-485 that allowed the client to quickly interface with various RS-485 systems for development purposes. While the device can act as a simple bridge between USB serial and RS-485 the programmability and on-board microcontroller allows the developer to also implement code to manage the strict timing requirements of certain protocols.

MOVIE PROP - RADIO CONTROLLED LED

We manufactured this radio remote controlled, battery operated, LED device. This included machining of the case and curved acrylic display window. The device was used in the Swedish TV-series "Bron" by Anagram.

REMOTE CONTROLLED CAR

We designed the remote control system and mechanics for this Chevrolet Captiva for an advertisement video.

Watch the video of the first test drive

MOVIE PROP - TECH IN A BOX

We crafted and programmed these two panels, designed to imitate the look and behavior of various electronic devices. Used in the filming of the movie "Väster om friheten" by Anagram.

Watch the video

CONTROL PANEL

Control panel with ethernet connectivity for remotely controlling motion systems.

Features analog joystick and high resolution rotary encoder, direct access to important parameters as well as remote connection and position save/recall. The LCD menu system provides access to parameters of lesser importance as well as network and remote device set-up.

SPHERICAL CIRCUIT BOARD

We designed and assembled this spherical circuit board.

The design is a second iteration geodesic sphere and each segment has an "intelligent" RGB LED.

Contained inside is a battery back, microprocessor and accelerometer.

Watch the video

INTERLOCKING RADIO KEYPAD SYSTEM

Remote door passage system with central command and override functionality.

INDUSTRIAL CONTROL PANEL

We constructed this replacement control panel for an industrial hydraulic press, as the old panel was in bad shape.

The panel was constructed from sheet steel and designed to attach on top of, and preserve, the original panel.

A small slot was machined into the original panel to allow an IDC interface cable to be attached.

MOTORIZED POTENTIOMETER DRIVER

Motorized potentiometers require a bit of effort to interface properly, thus we adopted our motion control IP to a smaller and cheaper processor and designed a backpack board to all do the heavy lifting.

The board interfaces using SPI, I2C or UART and apart from the obvious read/recall functionality we also provide detent emulation, spring modeling, inertia and other configurable force feedback possibilities.

Watch the video

REMOTE CONTROLLED AMPLIFIER

This HI-FI grade remote controlled amplifier was designed, machined and assembled entirely in-house.

Features IR remote control, OLED display with lens and audio visualization capabilities.

MINIATURE CNC CIRCULAR SAW

This is an experimental low-cost mechanical construction of a micro-sized CNC-controlled diamond blade cutter that we designed to cut arbitrary electronics strips and various other materials - all based on an open source embedded vision system coupled with our own motion control IP.

Watch the video showing motion profiling, the accompanying universal feeding mechanism and careful cutting.

MOVIE PROP - TELEPHONE RINGER

DSp was tasked to construct a four line telephone ringing system for older phones. Telephones are powered by a DC voltage of about 50V and rung by an AC signal of about 100V, 25Hz (Swedish standard). We built this mains connected box with four buttons to handle the task.

METAL FLOWERS

This sample of an austere aluminum tealight holder was designed, machined, brushed and assembled right here in our workshop.

METAL BRACKETS

For this project DSp did CAD & CAM, CNC-machining, heat bending and a finishing coat of matte black paint - producing these replacement mounting brackets that add additional spacing for cables and the option of mounting various additional electronics peripherals.

MULTI-TOUCH LED-DISPLAY

An interactive LED-display based on shadow sensing (blocked ambient light) for use in an interactive installation where cameras and other means of detection were not acceptable. We designed and assembled this prototype system with LED overdrive capability allowing it to be used in direct sunlight. Sensors are tightly synchronized with LED PWM output such that the LED light does not interfere with ambient light sensing.

Watch the video

MOUNTING SYSTEM

This is our design for a system of modular spacers, brackets and clamps that enables you to mount of motorized drives and other peripherals to camera optics of arbitrary diameters and configurations.

All parts were designed, manufactured and tested by DSp before they were sent to the factory for production.

GEARS AND GEARBOX

This is a system of involute and GT2 gears that we designed and manufactured from POM plastic to produce a compact spring loaded, zero backlash, motor+gearbox solution. The housing was machined and assembled from 2mm aluminum and 3x6x2 ball bearings.

POE FOOT PEDAL

A programmable foot pedal with Power-over-Ethernet connectivity that we designed, machined and assembled here at DSp. The pedal features non-contact hall effect sensing of the pedal angle as well as a rugged industrial toggle switch on the right hand foot rest.

ROBOTIC ARM

This robotic arm had been left for dead, but with some programming wizardry we quickly brought it back to life.

Sadly, the museum installation that this was to be used for never came to fruition.

FLIP DOT ARTS DISPLAY

A speculative project done as an experiment on interfacing old technology with modern electronics. This is an electromechanical flip disc/flip dot display from an old intercity bus that was disassembled and refitted with a modern microcontroller and custom circuit board. Speed was increased nearly 20-fold over the original system allowing us to repurpose the sign - for ART!

F.LASHES INTERACTIVE LED EYELASHES

DSp was a co-creator of Tien Phams F.LASHES - Fun, interactive LED eyelashes Kickstarter project.

We were tightly involved in all aspects of the prototyping, design, electronics, programming and mass production installment for the project. Sadly the project was closed down when low-quality Chinese knock-offs flooded the market with ultra-low cost copies.

Watch the video feature from TOP KNOT

RING MOTOR

We designed the electromagnetics, mechanics and enclosure for this ring motor with a central iris mechanism. The prototype was machined and assembled in our workshop. The motor is a three-phase stepper motor with the stator coils acting on a rotor composed of permanent magnets in a Hallbach arrangement.

Watch the video of the prototype during testing

TRAINING CYCLE STEERING SENSOR

This break-off kit of aluminum parts was designed and manufactured by DSp as an easy to install add-on for our clients already existing training bike product. The kit reads the angle of the steering wheel and presents itself as a gamepad when connected to a PC, allowing a higher degree of immersion into their VR training product. The client previously used the accelerometer in an iPad to read the angle, but had obvious problems when the steering wheel was adjusted to a (near) vertical position - not to mention the unnecessary cost.

BLACK VELVET FRUIT BOWLS

We designed and laser cut this series of exclusive fruit bowls of various sizes. The design was assembled and finished with a rubber based velvet-like coating, making them soft to the touch and quite appealing in appearance.

WOODEN CLOCK

DSp did CAM and CNC-milling of the parts, and assembled this interesting wooden clock from walnut, beech and mahogany. The clock is powered by an off the shelf battery powered clock mechanism.

WOODEN JEWLERY CASE

This series of ornate wooden jewelery cases was designed and machined by DSp, from high grade white oak wood.

ALGORITHMICALLY GENERATED PLANTLIFE

To shorten the design phase of several unique sky-light vinyl prints, we developed an algorithmic approach to generating vines and leaves that allowed us to quickly assemble multiple unique, naturally beautiful but tightly controlled floral designs that were then plotted onto black vinyl right here in our workshop.

DECORATIVE AIR INTAKE COVERS

These air intake covers were designed and fabricated by DSp to replace a series of original covers that the client was not happy with as they did not provide a tight enough seal due to their low-quality construction.

WOODEN STAND FOR PLAQUE

A beautifully engraved and finished wooden stand for a memorial plaque produced from a slab of birch wood.

Finished by fine-grained sanding, buffing and sealed with oil.

METAL AND RUST

A commissioned piece of vector artwork on an old steel plate that we crafted using vinyl cutting and acid etching to produce a thin layer of iron oxide that contrasts nicely against the polished steel surface. The piece was finished by locking the oxide in using a thick layer of carefully applied clear coat that also further accentuates the design.

ROTATING DISPLAY STAND

Design and manufacturing of for a battery operated rotating display stand with configurable speed and an appealing high quality black gloss finish. The parts were cut from HDF and integrates a simple bearing with 10mm metal balls.

Watch the video of the unit being assembled

ENCODER WHEEL DESIGN

DSp designed an algorithm and software solution to produce and later decode these encoder wheels that enable local homing. The LFSR based code on the rim allows absolute position recovery by reading any 7-bit section, in any direction, anywhere on the wheel, eliminating the need for returning all the way to a preset zero mark on start-up, instead moving only roughly 20 degrees in any direction to recover the current position.

LASER TAG SYSTEM & GUN

This is a laser tag system we designed to connect with your cell-phone to enable open-world laser games. In addition to designing the electronics and software, we also designed and manufactured this one-off prototype grip, complete with a spring loaded battery compartment and a housing for the electronics and optics in the shape of a pistol.

LASER ENGRAVING ON GLASS

These items are the result of our research into glass engraving and cutting. We designed a number of algorithms, processes and CNC machine heads that allow us to score, cut and engrave glass under CNC control. The photographic designs are produced using a special process involving Voronoi maps overlaid onto bitmaps to provide the sense of much higher resolution by generating point clouds that follow the "flow" of features in the original image.

THREE IN A ROW

This simple game was commissioned to be manufactured from a specific piece of wood holding high sentimental value and with symbols scanned from an old hand drawn game of three in a row.

GRADUATION SIGN

We designed and produced this exclusive graduation sign from mahogany, plywood and frosted acrylic.

The fabrication involved CNC milling, laser cutting and vinyl plotting.

ELECTROMECHANICAL SIGN

For a sporting event, we were requested to re-furbish and re-purpose this old electromechanical 7-segment display using modern electronics and radio remote control. It always makes us happy to see old electronics given new life and as an added bonus - we got to keep all of the spare displays.

Watch the video of the final display being profiled for maximum speed

SLIDING DOOR MECHANISM

This simple opening mechanism for a sliding double door of a display cabinet was designed using only readily available low-cost parts, machined and assembled in our workshop. It was originally driven by a standard NEMA 23 stepper motor but later replaced with a servo motor to reduce the noise.

SIGNAGE / COVER PANEL

Quick machining job - an MDF sign/cover panel with the CINCO logotype.

Results of CNC machining and sanding can be quite pleasing even with simple materials such as MDF.

CIGARILLO CASE

DSp designed and machined this exclusive cigarillo case with a nicotine molecule engraved on the diametrically brushed aluminum lid. The case closes magnetically and was machined with a specially crafted method to produce a beautiful pearl patterning on the inside of the case, straight from the machine without the need for further finishing.

RABBIT HOUSE

Non-profit project, ordered by a family member :)

Carpentry can be a lot of fun, especially when there is a laser cutter involved.

BEATLES WALL LAMP

This unique wall lamp was produced by CNC-machining a 12" vinyl record and as a frosted acrylic backing.

The client provided us with the design and assembled the piece himself.

VINYL RECORDING DEVICE

A small experimental electromechanical device for doing (very lo-fi) sound recordings on vinyl blanks (or other materials cut to a playable shape). Designed, machined and assembled by DSp.

MAGNETIC NON-CONTACT X-Y TABLE

This is our prototype CNC operated X-Y manipulation table. It uses magnets on a PTFE (Teflon) sheet to provide a chemically resistant, non-contact interface between the mechanics and manipulation surface.

THE "DESKTOP SHREDDER"

A one-afternoon project done for no other reason than pure, unadulterated fun. Also very dangerous - don't do at home!

Watch the video of us shredding all sorts of things found in the workshop

REMOTE IGNITION

High-voltage electrical spark generator for remote gas ignition in fire safety demonstrations.

Watch the video

ALUMINUM JEWELERY & DECOR

A few of the commissioned and speculative pieces machined from aluminum that we have done over the years.

OMNIDIRECTIONAL ROBOT

We designed and built several of these omnidirectional platforms. They can move in any direction at any time, are controlled over WiFi and has video feedback. The system is based on a 12V powered micro-ITX PC with a completely custom software solution for control and video return feed that supports low speed and lossy connections over UDP, while maintaining very low latency.
